Details

Performance Overview

Size	Load Capacity	Material
8'	350 lbs	Wood

Specifications

Size: 8'
Floor to Ceiling Height Range: 7' to 8'9"
Rough Opening Width x Length: 25" x 54"
Load Capacity: 350 lbs
Ladder Width: 16-3/4"
Landing Space Range: 4' 8"
Swing Clearance: 5' 2"
Foot Material: wood
Locking Device: Spring
Opening Device: Rope
Door Material: Plywood
Frame Material: Pine
Full Width Door hinge: Yes
Metal-to-Metal Rail hinge: Yes
Requires Cutting Foot Angle: Yes
Number of People for Installation: 2
Certifications: ANSI A14.9 (2010)
Approx. Cu. Ft. Per Unit: 12
Approx. Shipping Wt. Lbs.: 62.5

Dimensions

Rail Size: 3/4" x 4-1/2"
Step Length: 15-1/4"
Step Width: 4-1/2"
Grooved Steps-Actual Lumber Size: 3/4" x 4-1/2"

Additional WH Series Models

Model No.	Size	Floor to Ceiling Height Range	Rough Opening Width x Length	Ladder Width	Landing Space Range
WH2208	8'	7' to 8'9"	22-1/2" x 54"	14-1/4"	4' 8"
WH2210	10'	8'9" to 10'3"	22-1/2" x 54"	14-1/4"	5' 4"
WH2508	8'	7' to 8'9"	25" x 54"	16-3/4"	4' 8"
WH2510	10'	8'9" to 10'3"	25" x 54"	16-3/4"	5' 4"
WH3008	8'	7' to 8'9"	30-1/2" x 54"	22-1/4"	4' 8"
WH3010	10'	8'9" to 10'3"	30-1/2" x 54"	22-1/4"	5' 4"

Additional Information

Manufacturer: Werner Co.
